FILLING NEEDLES
Fill4Sure
Filling Needles
Fill4Sure Filling Needles provide a needle for every drug product application or filling machine. SaniSure® offers ready-made and tailormade needles providing 100% coverage across the fill-finish arena, uncoupling the restrictions posed by OEM needles.
Fill4Sure Filling Needles are made from premium 316L stainless steel with polycarbonate housings in an oil- and adhesive-free manufacturing process. Filling speed, precision, and accuracy are at the heart of the design process.
Tailormade precision filling for single-use applications
The SaniSure® Fill4Sure Filling Needles break down the barriers of OEM needles while providing superior filling precision, accuracy, and finish for any drug-product filling application.
Overview
Fill4Sure Filling Needles
APPLICATIONS
- Cell and gene therapy filling
- Drug product vial filling
- Syringe filling
- Pre-lyophilization filling
- Co-axial liquid/gas filling
BENEFITS
- Repeatable performance in a single-use format
- Oil- and Adhesive-free construction
- Tailor-made needle design
- Premium construction materials
SPECIFICATIONS
- 0.6 – 6.0 mm ID’s
- 125.1 – 186.2 mm needle lengths
- Gamma-irradtiation suitable
| Standard IDs range from 0.8mm to 6.0mm | Overall Lengths range from 125.1mm to 165.0mm |
| ID (mm) | Length (mm) |
| 0.8 | 125.1 |
| 1.1 | 138.2 |
| 1.5 | 154.5 |
| 2.1 | 165 |
| 2.5 | 181.6 |
| 3 | |
| 3.5 | |
| 3.6 | |
| 4 | |
| 4.5 | |
| 5 | |
| 6 |
1. Standard Housing
Housing Diameters: 8mm, 10mm, 13mm
2. Friction-Fit Housing
Housing Diameters: 6.35mm (0.25”), 9.52mm (0.375”), 13mm, 15-20mm
3. Friction-Fit Housing with O-ring
4. Reduction Housing
5. No Hose Barb Housing
6. Snap-Fit Stainless Steel Filling Needles
1. Co-Axial Filling Needles
For simultaneous filling of a gas overlay (outer tubing) and liquid product (inner tubing) at the same filling station.
2. Penetrating Filling Needles
For removal of product through an overseal using a Filling Needle
You might also be interested in
Looking for tailormade Filling Needles?
The SaniSure® Fill4Sure Filling Needles can be customized according to each project’s needs.
Learn more about how we can cover your fill-finish challenges.
